OBU M - Modern Waterproof GPS Tracker with Removal Notification
Professional Installation IPX5 Rated

OBU M
The Most Modern

Waterproof, supports electric vehicles, and notifies when device is removed. Maximum security!

Powered by Lynk Secure payment with Lynk
OBU M GPS Tracker 1
OBU M GPS Tracker 2
OBU M GPS Tracker 3
OBU M GPS Tracker 4
OBU M GPS Tracker 5
OBU M GPS Tracker 6
OBU M GPS Tracker 7
OBU M GPS Tracker 8
9-90V Modern

Product Video

OBU M Modern Tracker - Product Overview

Advanced tracking solution for electric vehicles and motorcycles, with weather-resistant features and high-level security.

Premium Features

Maximum protection with advanced technology for your peace of mind

Real-time Tracking

Wide network coverage across Indonesia

Engine Detection

Get alerts when your vehicle is started

Tamper Detection

Alert for device damage, removal, or hacking

IPX5 Rating

Water and dust resistant

Voltage 9-90V

Resistance to all currents

Various Vehicles

Suitable for motorcycles and electric cars

Why Choose OBU M?

Modern tracking solution for electric vehicles and motorcycles with cutting-edge technology

Voice Monitoring

Listen to sounds inside the vehicle from up to 3 meters away

Multi-Sensor

Accelerometer and ACC detection for more accurate detection

Industrial Grade

100mAh industrial grade battery for maximum durability

Technical Specifications

Advanced hardware with cutting-edge technology for maximum performance

100
mAh
IPX5
Rating
26.6
Gram
< 2.5m
Accuracy

Global Navigation Satellite System (GNSS)

Positioning System

GPS + BDS + LBS
Positioning Accuracy: < 2.5m CEP
Tracking Sensitivity: -165 dBm

Cellular

Network

GSM - Quad-band 850/900/1800/1900 MHz

Power

Battery

100mAh / 3.7V Li-Polymer (Industrial Grade)
Input Voltage: 9–90VDC

Physical & Interface

Physical Specification

Dimensions: 73.8mm × 25.9mm × 12.2mm
Weight: 26.6 g

Interface

LED: GPS (Blue), GSM (Green)
SIM: Micro SIM
Data Storage: 32 + 32 Mb
Connector: Power Cable

Operating Environment

Temperature

Operating: -20°C to +70°C

Humidity & IP Rating

Humidity: 5% – 95%, non-condensing
IP Rating: IPX5

Features

Sensors

Accelerometer
Ignition Detection: ACC Detection
Tamper Alert: Power disconnection

Voice Monitoring

< 3 meters
ORIN GPS Tracker Activation Guide

OBU M Series – Professional Installation

Reliable industrial tracking solution.

Product Specifications

Positioning System
GPS + BDS + LBS
Input Voltage
9 – 90V DC
Battery
100mAh (Industrial Grade)
Key Features
Voice Monitoring, ACC Detection
1

Install on Vehicle

Attention!
This unit is a professional installation GPS that requires specialized technician assistance.
2

Access & Download

Web
app.orin.id
App
ORIN – GPS Tracking
3

Register

1
Click Register Now
2
Fill in Name, Email, WhatsApp, & Password
4

Add Unit

Login > Unit Menu > Click (+) > Fill Data (IMEI, GSM No, Unit Name) > Click Add Unit
5

Perform Reset

Use the Restart/Reset Unit feature in the ORIN App or Web if the unit has issues

Perform Reset

If the unit has issues, you can perform a reset independently via:

App: Select Unit > Click Restart Unit
Web: Select Unit > Click Reset Unit

📞 Contact Our CS

Need help? Our team is ready to assist you

WhatsApp Support
0813 2929 3939

Ready to Protect Your Vehicle?

Get OBU M now and enjoy peace of mind with maximum protection for your electric vehicles and motorcycles.
